The physical specifications of network cable jumpers determine their basic transmission capabilities, mechanical strength, and flexibility, laying the foundation for stable data transmission.

I. Physical Specification Parameters: The Material Foundation of Transmission Performance

The physical specifications of network cable jumpers determine their basic transmission capabilities, mechanical strength, and flexibility, laying the foundation for stable data transmission.

1. Conductor Material and Structure

The conductor is the core carrier of electrical signal transmission in network jumpers, and its material and structure directly affect conductivity, signal integrity, and oxidation resistance:

Core Materials:

Oxygen-Free Copper (OFC): With a purity of ≥99.95% and oxygen content ≤0.003%, it has excellent conductivity (electrical conductivity ≥100% IACS). The resistivity at 20°C is ≤0.0172Ω·mm²/m, which can effectively reduce signal transmission loss. It is the mainstream material for high-performance network jumpers (such as Cat6 and above).

Tinned Copper: A layer of 2-5μm tin is plated on the surface of oxygen-free copper conductors. Tin can prevent copper oxidation (the oxidation resistance is 5 times that of bare copper), ensuring stable conductivity even in humid environments (such as computer rooms with high air conditioning humidity). It is commonly used in data center jumpers.

Copper-Clad Aluminum (CCA): Aluminum core is coated with a thin layer of copper. Its conductivity is only 60%-70% of that of oxygen-free copper, and the resistivity is ≥0.028Ω·mm²/m. The signal attenuation is large, and it is only used in low-end jumpers (such as Cat5e for temporary connections) due to its low cost.

Copper-Clad Steel (CCS): Steel core with copper plating has high mechanical strength but poor conductivity (conductivity ≤30% IACS). It is only used in special scenarios requiring tensile strength (such as outdoor short-distance connections), not suitable for high-speed data transmission.

Conductor Structure:

Solid Conductor: A single solid copper wire with a diameter of 0.4-0.6mm (common specifications: 24AWG, 23AWG). It has stable signal transmission performance and low attenuation, but poor flexibility (minimum bending radius ≥8 times the cable diameter). It is suitable for fixed wiring in patch panels and equipment rooms.

Stranded Conductor: Composed of 7-19 fine copper wires (each wire diameter 0.08-0.1mm) twisted together. It has excellent flexibility (minimum bending radius ≥4 times the cable diameter) and can withstand ≥10,000 bending tests without breaking. It is suitable for jumpers that need frequent plugging and unplugging (such as connections between switches and servers).

2. Cable Size and Weight

The size and weight of network jumpers affect their installation convenience, space occupation, and structural stability:

Conductor Gauge: Expressed in AWG (American Wire Gauge). Common specifications for network jumpers are 24AWG (diameter 0.511mm) and 23AWG (diameter 0.573mm). Under the same length, 23AWG conductors have a larger cross-sectional area than 24AWG, with 15%-20% lower attenuation. They are suitable for high-frequency transmission (≥500MHz) and long-distance jumpers (≥5m).

Cable Outer Diameter: Varies with cable categories and shielding types. Unshielded (UTP) Cat6 jumpers have an outer diameter of 5-6mm; shielded (STP) Cat6a jumpers have an outer diameter of 6-8mm due to the additional shielding layer. A larger outer diameter provides better protection but occupies more space, so it needs to be selected according to the wiring density (such as high-density cabinets in data centers).

Weight: 24AWG UTP jumpers weigh 12-18g/m; 23AWG STP jumpers weigh 20-25g/m due to the shielding layer and thicker conductors. Lightweight jumpers are easier to manage (such as bundling and routing), while heavy-duty jumpers have better durability.

3. Insulation and Sheath Materials

Insulation materials isolate adjacent conductors to prevent crosstalk, and sheath materials protect the cable from mechanical damage and environmental erosion:

Insulation Materials:

HDPE (High-Density Polyethylene): It has excellent electrical insulation performance (dielectric constant 2.3-2.4) and low water absorption (≤0.01%/24h). It can maintain stable performance in the temperature range of -40°C to +80°C. It is the main insulation material for network jumpers, ensuring low capacitance between conductors (capacitance ≤56pF/m).

PP (Polypropylene): Similar to HDPE in performance but with higher rigidity. It is often used in the insulation of stranded conductors to enhance the structural stability of the conductor bundle.

Foamed HDPE: By adding foaming agents to HDPE, the dielectric constant is reduced to 1.8-2.0, which can further reduce signal attenuation (attenuation at 100MHz is 10% lower than that of solid HDPE). It is used in high-frequency jumpers (such as Cat6a and Cat7).

Sheath Materials:

PVC (Polyvinyl Chloride): Low cost, flame retardant (UL94 V-2 grade), and operating temperature range of -15°C to +60°C. It is suitable for indoor dry environments (such as office networks). However, it is prone to hardening at low temperatures and releases harmful gases when burned.

LSZH (Low Smoke Zero Halogen): No halogen elements, low smoke generation when burned (smoke density ≤50% of PVC), and non-toxic gas emission. The flame retardant grade can reach UL94 V-0, and the operating temperature range is -20°C to +70°C. It is mandatory for data centers, subway, and ship networks with high safety requirements.

PE (Polyethylene): Excellent flexibility and impact resistance, but poor flame retardancy (flammable). It is used in outdoor jumpers (with additional UV-resistant additives) to resist wind and rain erosion.

II. Electrical Performance Parameters: Core Indicators Determining Network Transmission Quality

Electrical performance is the most critical parameter of network jumpers, directly determining transmission rate, bandwidth, and signal stability.

1. Cable Category and Transmission Rate

Network jumpers are classified according to TIA/EIA-568 and ISO/IEC 11801 standards, and different categories correspond to different transmission capabilities:

Cat5e (Enhanced Category 5):

Bandwidth: Up to 100MHz.

Maximum transmission rate: 1000Mbps (Gigabit Ethernet) at 100m.

Key applications: Home networks, office desktops, and low-speed IoT devices.

Cat6 (Category 6):

Bandwidth: Up to 250MHz.

Maximum transmission rate: 10Gbps at 55m, 1000Mbps at 100m.

Improvements: Stricter crosstalk and attenuation indicators than Cat5e, with a longitudinal separator (plastic cross frame) to isolate four pairs of conductors, reducing mutual interference.

Applications: Enterprise Gigabit networks, video surveillance (4K cameras).

Cat6a (Augmented Category 6):

Bandwidth: Up to 500MHz.

Maximum transmission rate: 10Gbps at 100m.

Improvements: Better shielding or tighter twisting to reduce alien crosstalk (AXT), supporting full-duplex 10Gbps transmission over the entire 100m.

Applications: Data center 10Gbps backbone connections, high-definition video editing workstations.

Cat7 (Category 7):

Bandwidth: Up to 600MHz.

Maximum transmission rate: 10Gbps at 100m, 40Gbps at 50m.

Features: Fully shielded (SFTP structure), each pair of conductors is individually shielded, and the entire cable is covered with an outer shield. The shielding effectiveness is ≥85dB at 1GHz.

Applications: High-density data centers, 40G/100G Ethernet pre-connection.

Cat8.1/Cat8.2:

Bandwidth: Up to 2000MHz (Cat8.1) and 2400MHz (Cat8.2).

Maximum transmission rate: 40Gbps/100Gbps at 30m.

Features: Heavy-duty shielding, compatible with RJ45 and GG45 connectors, designed for short-distance high-speed connections between data center switches and servers.

2. Impedance Characteristic

The characteristic impedance of network jumpers is designed to match network equipment (typically 100Ω), which is crucial for reducing signal reflection and ensuring signal integrity:

Nominal Impedance: 100Ω ±20Ω (TIA/EIA standard), which needs to match the 100Ω impedance of network cards, switches, and other equipment.

Impedance Stability: The impedance fluctuation within the operating frequency range (0-2000MHz) should be ≤15Ω. Excessive fluctuation will cause signal reflection (reflection loss reduction), leading to bit errors.

Impedance Matching: The impedance difference between the jumper and the connected equipment should be ≤10Ω. Otherwise, signal reflection will occur at the connection point, and the reflection loss (RL) will be ≤10dB, affecting transmission stability.

3. Attenuation (Insertion Loss)

Attenuation refers to the loss of signal power during transmission, which increases with frequency and length:

Definition: Expressed in dB, the formula is attenuation = 20lg (input power/output power). The smaller the value, the better the transmission performance.

Specific Indicators:

Cat5e: At 100MHz, attenuation ≤24dB/100m.

Cat6: At 250MHz, attenuation ≤30dB/100m.

Cat6a: At 500MHz, attenuation ≤39dB/100m.

Cat7: At 600MHz, attenuation ≤40dB/100m.

Influencing Factors: Conductor material (oxygen-free copper has lower attenuation than CCA), cross-sectional area (thicker conductors reduce attenuation), and insulation material (foamed insulation has lower dielectric loss).

4. Crosstalk (Interference Between Conductors)

Crosstalk is the signal interference between adjacent conductor pairs, which is the main factor limiting transmission rate:

Near-End Crosstalk (NEXT): Interference from the transmitting end to the receiving end of adjacent pairs at the same end of the cable. The higher the frequency, the more serious the NEXT.

Standards: Cat6 requires NEXT ≥44dB at 250MHz; Cat6a requires NEXT ≥46dB at 500MHz.

Far-End Crosstalk (FEXT): Interference from the transmitting end to the receiving end of adjacent pairs at the far end of the cable. It is mainly affected by cable length and frequency.

Equal-Level Far-End Crosstalk (ELFEXT): FEXT minus attenuation, which better reflects actual interference. Cat6a requires ELFEXT ≥24dB at 500MHz.

Alien Crosstalk (AXT): Interference between different cables in the same bundle (such as multiple jumpers bundled together). It is a key indicator for Cat6a and above, requiring AXT ≥35dB at 500MHz for Cat6a.

Power Sum Near-End Crosstalk (PSNEXT): The sum of NEXT interference from all other pairs to a single pair, which is more stringent than NEXT. Cat6 requires PSNEXT ≥42dB at 250MHz.

5. Return Loss (RL)

Return loss is the ratio of reflected signal power to incident signal power, reflecting impedance matching:

Indicator: Expressed in dB, the larger the value, the less reflection. Cat6 requires RL ≥12dB at 250MHz; Cat6a requires RL ≥10dB at 500MHz.

Impact: Poor return loss (≤8dB) will cause signal distortion, leading to packet loss and retransmission, reducing network throughput.

6. Delay and Delay Skew

Propagation Delay: The time required for a signal to travel through the cable. For 100m jumpers, Cat6 requires propagation delay ≤555ns at 250MHz.

Delay Skew: The difference in propagation delay between the four pairs of conductors. It is critical for twisted-pair systems using all four pairs (such as 10Gbps Ethernet). Cat6 requires delay skew ≤50ns at 100m, ensuring that signals from different pairs arrive at the receiving end synchronously.
